WAYTON TECHNOLOGY CO., LTD.
メーカー特長
1994年に臺灣、高雄で設立された液晶ディスプレイモジュール（LCDモジュール）の専門企業です。 標準品だけでなく、お客様に合わせてカスタム製品を提供しています。
それに加えて、お客様の要求に応じてLCDモジュールを設計、製造等の液晶トータルソリューションと技術サービスを提供できることがWAYTONの大きな特徴です。
WAYTON Technology Co., Ltd. is a reliable and specialized company which is established in 1994 and located in Kaohsiung, Taiwan with wide and varied experience in designing and manufacturing Liquid Crystal Display Module (LCD Module). Not only standard products, we also have varied customized products and services for customers.
In addition to that, designing and manufacturing LCD Module in accordance with every customer’s requirement and providing integrated solution and technical service are the most well-known features of WAYTON.
取扱製品
- 高精度中型および大型TFT LCMを設計および製造する優れた能力。
- 容量性タッチパネル付きLCDモジュールの設計と製造に特化。
- インライン自動生産設備を設置し、高品質のLCDモジュールを製造する能力大。
| Number | Item | Specification |
| 1 | Type | transmissive |
| 2 | Display mode | normally white |
| 3 | Pixel element | a-Si TFT |
| 4 | Screen size | 7.0-inch |
| 5 | Resolution | 800 (RGB) x480 |
| 6 | Color number | 16.7M |
| 7 | Active area | 153.84 x 85.63mm |
| 8 | Pixel size | 0.1926 x 0.1790mm |
| 9 | Color arrangement | RGB-stripe |
| 10 | Assembly type | COG |
| 11 | Brightness | 350 (min.) cd/m2 |
| 12 | Good viewing direction | 12H |
| 13 | Gray scale inversion direction | 6H |
| 14 | Module dimension | 165.0 x 100.0 x 6.8mm |
| 15 | TFT Interface | RGB |
| 16 | RTP interface | 4-lane |
| Number | Item | Specification |
| 1 | Type | IPS / Transmissive |
| 2 | Display mode | Normally Black |
| 3 | Pixel element | a-Si TFT |
| 4 | Screen size | 10.1 Inch |
| 5 | Resolution | 1280 x RGB x 800 |
| 6 | Color number | 16.7M |
| 7 | Active area | 216.96 x 135.6 mm |
| 8 | Pixel size | 0.1695 x 0.1695mm |
| 9 | Color arrangement | RGB-Stripe |
| 10 | Assembly type | COG |
| 11 | Brightness | 250 (TYP.) cd/m2 |
| 12 | Viewing direction | Free |
| 13 | Module dimension | 248.8W x 174.5H x 4.1D (mm) |
| 14 | TFT Interface | LVDS |
| 15 | CTP interface | I2C |
